flange 100 mm
Height: 250 mm
Max. flow rate: 360 m3/h
Opt. Flow: 240 m3/h
Weight: 2.4 kg
The Eco Line range of activated carbon filters offers easy installation and high reliability. The activated carbon inside the filter effectively removes all odors from the room and allows the fans to work more efficiently than competing activated carbon filters. Ideal for cleaning the air flow of odors by physical or chemical absorption. The filter is suitable for a maximum air temperature of 70 °C and a maximum humidity of 70%.
To determine the correct size of activated carbon filter, you can calculate your desired filter volume in three simple steps. Measure the air volume in the room by multiplying the length, width and height of the room. Then multiply the air volume by 60 to get the amount of air that needs to be moved per hour.
